6061 7075 Aluminum Connecting Rod And Joints CNC Machined Ra 0.8-1.6μm
Product Overview
Our precision forged aluminum connecting rods and joints are engineered for superior performance in transmission and powertrain applications. Manufactured using advanced forging techniques, these components deliver exceptional strength-to-weight ratios, fatigue resistance, and dimensional accuracy, making them ideal for high-stress automotive, aerospace, and industrial applications.
Key Features & Benefits
Material Excellence
- Forged from 6061, 7075, or custom aluminum alloys for optimal durability and corrosion resistance.
- Enhanced grain structure for higher tensile strength compared to cast or machined parts.
Precision Engineering
- Tight tolerances (±0.05mm) for seamless integration into transmission systems.
- CNC-machined finishing for critical surfaces (bearing bores, thread profiles).
Performance Optimized
- 30-50% lighter than steel equivalents, reducing rotational mass and improving efficiency.
- Fatigue-tested for long-term reliability under dynamic loads.
Custom Solutions
- Tailored designs for gear linkages, shift mechanisms, drivetrain joints.
- Surface treatments available: Hard-coat anodizing, PTFE coating, shot peening.
Applications
- Automotive: Transmission shift rods, clutch linkages, suspension joints
- Aerospace: Flight control linkages, actuator components
- Heavy Machinery: Hydraulic system joints, industrial powertrains
Product parameters
| Parameter | Specification |
| Material | 6061-T6, 7075-T73 (other alloys available) |
| Forging Process | Closed-die hot forging |
| Tolerances | ±0.05mm (standard), ±0.02mm (high-precision) |
| Weight Reduction | 30-50% vs. steel equivalents |
| Tensile Strength | 6061: 310 MPa min | 7075: 570 MPa min |
| Yield Strength | 6061: 275 MPa min | 7075: 505 MPa min |
| Surface Finish | As-forged: Ra 3.2μm | Machined: Ra 0.8-1.6μm |
| Heat Treatment | T6 temper (solution heat treated + artificially aged) |
| Dimensions | Rod Length: 50-1500mm | Joint Diameter: 20-200mm (customizable) |
| Load Capacity | Dynamic: Up to 15kN | Static: Up to 45kN (depends on alloy/size) |
| Surface Treatments | Anodizing (Type II/III), Hard Coat, Powder Coating, PTFE |
| Certifications | ISO 9001, IATF 16949, material certs (EN 10204 3.1/3.2) |
| Testing Standards | Ultrasonic, Hardness (Brinell/Rockwell), Salt Spray (ASTM B117) |
Technical Parameters:
| Surface Finish | As-forged: Ra 3.2μm, Machined: Ra 0.8-1.6μm |
| Tolerance | ±0.01mm |
| Yield Strength | 6061: 275 MPa min, 7075: 505 MPa min |
| Product Category | Aluminum Forging Parts |
| Precision Engineering | Tight tolerances (±0.05mm) for seamless integration into transmission systems |
| Weight | Customized |
| Custom Solutions | Tailored designs for gear linkages, shift mechanisms, drivetrain joints |
| Lead Time | 4 - 6 WEEKS |
| Forging Process | Closed-die hot forging |
| Process | Forging |
Support and Services:
Our product technical support and services for Aluminum Forging Parts are designed to assist you with any questions or issues you may encounter. Our team of experts is available to provide guidance on product specifications, installation, maintenance, and troubleshooting.
We offer a range of services to ensure that your Aluminum Forging Parts perform optimally, including product training, on-site support, and warranty assistance. Our goal is to help you maximize the performance and longevity of your products.
Whether you have questions about product compatibility, performance optimization, or troubleshooting, our technical support team is here to help. Contact us for any assistance you may need with your Aluminum Forging Parts.
Packing and Shipping:
Product Packaging:
The aluminum forging parts are carefully packed in durable cardboard boxes to ensure safe transportation and delivery. Each part is securely wrapped and cushioned to prevent any damage during shipping.
Shipping Information:
Once your order is placed, the aluminum forging parts will be prepared for shipping within 1-2 business days. We offer both standard and expedited shipping options to meet your delivery needs. You will receive a tracking number to monitor the status of your shipment.
FAQ:
Q: What is the brand name of the Aluminum Forging Parts?
A: The brand name is Qingdao Sande Tech Co.,Ltd.
Q: What certifications do the Aluminum Forging Parts have?
A: The parts are certified with ISO, DIN, AISI, ASTM, BS, JIS, etc.
Q: Where is the place of origin for the Aluminum Forging Parts?
A: The parts originate from Qingdao, China.
Q: What is the minimum order quantity for the Aluminum Forging Parts?
A: The minimum order quantity is 1000 pieces.
Q: What are the accepted payment terms for purchasing the Aluminum Forging Parts?
A: The accepted payment terms are D/P, T/T, Western Union.
